Stock replacement for 99-06 Twin Cam 88™ 1450cc models.

Std cyl. bore: 3.75" (95.25mm).

1st ring: 1.5mm.

2nd ring: 1.5mm.

Oil ring: 3.0mm.

Tech tip: Piston grooves vs piston rings.

It's not difficult to determine if a Hastings piston ring set will fit a certain piston. You should measure the height of the piston groove in the piston itself. The 2 top grooves will be for compression rings, the lower groove will be for the oil ring. In most cases Hastings oil rings are of the low tension 3-piece flex vent type. Ring heights are listed for reference.

Tech tip: Piston oversizes.

For each oversize cylinder diameter will increase with .010" (0.254mm). The standard bore of the cylinder is listed for reference.

(Information provided by Hastings Manufacturing Company, Inc.)
